Advantages of the ZTRFM Kr24 Portable Standing Seam Roll Former Machine:

Portable Design - Equipped with wheels, allowing easy transport to construction sites for on-site production.

Multi-Size Production - Capable of producing various sizes without the need for mold or blade changes.

Simple Setup - Integrated control system and hydraulic station; only requires connecting the main power cable.

Optional Ribbing - Rib designs are available as an option.

Standing Seam Metal Roofing Machine Description：

The ZTRFM Kr24 standing seam metal roof panel machine comes in various models compatible with corrugated, IBR, or glazed tile sheets, as well as self-locking roof systems. Kr24 panels are widely used in industrial factories, residential buildings, and as roof boards for attachments due to their attractive appearance and long-lasting durability.

The Kr24 profile is especially popular in Mexico. Its jointed panels are rolled on-site with portable equipment, making transportation and installation straightforward. This design features a concealed clip-based fastening system, eliminating the need for surface drilling, which significantly reduces maintenance costs and enhances waterproofing.

The SSR-type (Standing Seam Roof) KR24 sheet is ribbed and connected directly on-site. Its hidden clip system minimizes leak risks, as no drilling is needed during installation. Manufactured in continuous lengths from gutter to ridge, KR24 sheets allow for insulation materials to be added and can be installed on roofs with low slopes down to 2%.

Pattern Drawing :

Application of the ZTRFM Kr24 roof panel：

Working flow：

Decoiler--feeding--roll forming--cut to length--output table

The Technical Specifications Of The Kr24 Standing Seam Metal Roofing Machine：

ZTRFM China Kr24 Portable Standing Seam Roll Former Machine
1.Formed Material	PPGI,GI,AI	Thickness:0.3-0.6mm
2.Decoiler	Hydraulic automatic decoiler	Manual decoiler(will give you as free）
3.Main body	Roller station	7 rows(As your requirement)
	Diameter of shaft	60mm solid shaft
	Material of rollers	45# steel, hard chrome plated on the surface
	Machine body frame	Square tube welded with steel panel
	Drive	Gear transmission
	Dimension(L*W*H)	2300*1500*1600(customize)
	Weight	2.2T
4.Cutter	Automatic	cr12mov material, no scratches, no deformation
5.Power	Motor Power	4KW
	Hydraulic system power	3KW
6.Voltage	380V 50Hz 3Phase	As your requirement
7.Control system	Electric Box	Customized(famous brand)
	Language	English(Support multiple languages)
	PLC	Automatic production of the whole machine. Can set batch, length, quantity, etc.
8.Forming Speed	0-15m/min	The speed is adjustable

More pictures of the machine：

1、3 Ton Manual Decoiler：

2、 Hydraulic cutting system：

3、The control panel with multi order input：
