Description Of Strut Channel Roll Forming Machine

We are a professional manufacturer specializing in C channels, unistrut, solar panel stands, and seismic stabilizer stand roll forming machines. Our machines can produce various sizes of C channels, with flange adjustments available in both manual and automatic modes to meet customer requirements.

Cutting options include saw cutting and hydraulic cutting, depending on your specifications. Additionally, our machines feature a punching system, with some customers opting for hydraulic punching, others for punching presses, and some choosing to punch holes after forming the C channel using a separate machine, enhancing production efficiency.

Operating our machines is straightforward and user-friendly. We primarily work with pre-galvanized steel, hot-rolled and cold-rolled steel, as well as stainless steel, with material thicknesses ranging from 1.5 mm to 2.5 mm. The most commonly requested strut channel profile sizes include 41x21, 41x41, 41x62, and 41x82.

For more detailed information about our machines, please feel free to contact us.

Purpose of the Equipment:

- Designed primarily for producing strut channels used in solar photovoltaic mounting systems.

- These channels are essential for installing, supporting, and connecting lightweight structural loads in construction projects.

Product Specifications:

- Capable of producing a diverse range of strut channel specifications and types, including:

- Solid channels

- Slotted channels

- Half-slotted channels

- Long-slotted channels

- Perforated channels

- Combinations of perforated and slotted channels

Machine Features:

- High precision and long service life ensure the quality and stability of the produced strut channels.

- User-friendly design reduces the skill level required for operators.

Profile Drawing:

Strut Channel Roll Forming Machine Working Flow:

Automatic feeder(3T) → leveling → punching  → roll forming machine → re-forming →  saw cutting → output

 The Technical Specifications Of the strut channel Rolling Forming Machine:

Strut Channel Forming Machine
Series	Details	Parameter	Comment
Material	Raw material	Galvanized steel	Customer confirmed
	Material thickness	1-2 mm
Decoiler	Roller station	25 station	The standard one to match the production line
		upper 3 + down 4 to level the coil.
	Loading capacity	3 Tons
	Coil inner diameter	450-600 mm
Roll forming machine	Guiding device	Placed on the machine by seller
	Rolling shaft material	45# steel with tempering treatment
	Shaft diameter	70 mm
	Roller material	GCr12MoV
	Rolling station	18 stations
	Work speed	0-35 m/min (without punching holes) 0-20m/min (with holes)
	Machine structure	Vertical memorial arch frame
	Machine basic frame	Steel plate welded
	Bearing	Chinese famous brand Harbin	Famous brand of Harbin
	Work power	7.5 kw+7.5kw+7.5kw
	Transmission	Gear box transmission	With cover
	Safety cover	available
	Appearance	Good appearance with no burrs in steel body nor traces of rust or defects in painting. Good electrical and hydraulic cable organization Car painting make the machine more glossy	We confirm each detail can match the standard, ensure the machine is 100% new!
	Decoiler, we can change to hydraulic one if you need.

Applications:

End Product：

More detailed pictures of the machine：

Part 1: Decoiler

Part 2: Roll forming system

Part 4: PLC control system

Part 5: Shearing system

Part 6: Receiving table
